Breathie Thingy P.A.P.R
The powered respirator is used for dust removal and partial odor removal, not for gases or vapors and is used to reduce or remove resistance to inhalation during respiration - by producing a constant airflow. The unit is designed with manufacturer's minimum design flow rate 170 litres, 210 litres or 250 litres per minute ( the flow rate at which the equipment still will fulfill the requirements of the class in either EN12942 or EN12941). The actual working time will be about 8 hours. Except the welding industry, our respirator also can be used in other industries (such as spraying).
Auto darkening welding helmet
Can be used with respirator
Model: UN09
Viewing size: 98*62mm
Filter Dimension (mm): 110*90*9mm
Light State Shade: DIN4
Dark State Shade: DIN9-13
Shade Control Ways: External
Switching Time: <1/25000s
Sensitivity Control: YES
Delay Time: 0.1-0.9s
UV/IR Protection Class: DIN16
Working Temperature: Between - 10 And 55 ℃
Power Supply: Solar Cell & Lithium Batteries
Air filter
Filtration Efficiency: 99.97%
Airflow: 170 L/min, 210L/min, 250L/min Charging time: 1h
Rechargeable time: >500 times Working humidity: <90% Storage humidity:
<85% Air filter class: P3
Powered respirator
Three layers of filtration more perfect effect
Stainless steel mesh (pre-filtration)
Activated carbon filter (odor sorption)
Air filter (solid particles, smoke and other pollutants' filtration)
Charger
Type: Fully automatic, overcharge protection
Primary voltage: 100-240 V, 50/60 Hz
Secondary voltage: 12.6 Volt
Color: Black
Weight: 200 grams
Dimensions: 110*48*30 mm
Hose
Type: Fully automatic, overcharge protection
Primary voltage: 100-240 V, 50/60 Hz
Secondary voltage: 12.6 Volt
Color: Black
Weight: 200 grams
Dimensions: 110*48*30 mm
Battery
Type: Lithium, rechargeable
Voltage: 12 Volt
Capacity: 5200 mAh
Operating time: H: 7 Hours, M: 9 Hours, L: 11 Hours
Charging time: 3 hours
Charging cycles: >500 times
Case material: Impact proof ABS
Color: Black
Weight: 350 grams
Dimensions: 137*50*72 mm
